LIGHT INTERMEDIATE - EN B

  • 20% Less Line Drag
  • Refined Shark Nose Profile
  • G-String Leading Edge
  • Double 3D Shaping

제품 설명

Lighter, higher performance, and more fun than ever!

The new Geo 6 is the largest performance increase, and weight decrease, in the history of the series. This all new design delivers significantly better speed and glide throughout the entire speed range, with True Performance in active air. Modern construction techniques and a clever blend of materials have saved 350 grams of weight compared to its predecessor.

This is the ideal travel & adventure wing in the intermediate range. With highly capable XC performance and very low weight and pack volume, it carries as well as it glides. When paired with the SOLOS harness, the total weight is under 7kg for an easy and comfortable lightweight XC kit.

NEW TECH

The Shark Nose profile has been improved by refining the openings for improved pressurisation at all angles of attack and adding G-Strings, as seen on the Rush 5. G-String straps maintain a cleaner opening shape during accelerated flight, and aid re-inflation behaviour, meaning that collapses open faster with less height loss. The leading edge benefits from double 3D shaping and improved sail tension in this aerodynamically critical area.

NEW INTERNAL STRUCTURE

The G6’s glide performance in active air and accelerated flight is significantly improved thanks to spanwise straps and modified cross-ports which have improved cohesion, tension, and spanwise flow, resulting in better turbulence absorption with reduced sail deformation.

MATERIALS

The G6’s internal structure is engineered for longevity. The top surface is made from a mix of Dominico 20D and Porcher 27 Classic, and the lower surface from Porcher 27 Classic. It is 1.55kgs lighter than the Buzz Z6 and 350g lighter than its predecessor without compromising strength or durability!

LAUNCH & FLIGHT

Above all, the G6 is comfortable and easy to fly. Thanks to a lighter sail, improved efficiency, and a more cohesive and agile feel, launching and ground-handling have never been easier. In the air, the handling is intuitive, fun, and super agile. Brake input is progressive, with a precise feel. In thermals and active air, the structural improvements create a comfortable yet informative wing.

Lightweight and low pack volume, the Geo 6 is ideal for traveling pilots and hike & fly missions. It’s for pilots who generally fly 30-50 hours per year, or for more experienced pilots seeking high levels of passive safety.

칼라 옵션

GEO 6 Colour Options

주문 정보

Lead time is currently unavailable. Contact your dealer for more information or to place an order.

패키지 용품

OZONE offers a range of backpack choices when you order your wing. To change the type of backpack that will come with your wing, please speak with your OZONE Dealer.

오존 날개 구입시 다음 액서사리가 기본으로 제공됩니다.:

130L Lightweight Backpack, Inner Bag, Glider Strap, OZONE Stickers, Repair Cloth and OZONE Keyring.

You may choose to add something to your order, such as: Saucisse Bag (video) (concertina packing bag), Easy Bag (quick stuff sack), or OZONE Clothing and Accessories.

제품 사양

크기xssmsmll
셀 갯수4848484848
투영 면적(m2)18.720.321.82324.5
평면 면적(m2)22.224.125.827.329
투영 스판(m)8.238.578.879.129.4
평면 스판(m)10.6911.1411.5211.8512.22
투영 면적 비율3.623.623.623.623.62
평면 면적 비율5.165.165.165.165.16
루트 크로드(m)2.632.742.842.923.01
글라이더 무게(kg)3.263.493.673.854.1
Certified Weight Range (kg)55-7065-8575-9585-10595-115
Recommended Flying Weight (kg)60-7070-8482-9490-104100-114
LTF / ENBBBBB

재료

  • Top Surface Cloth: Dominico N20D / Skytex 27 Classic
  • Bottom Surface Cloth: Skytex 27 Classic
  • Rib cloth: "Dominico 20D_32 / Skytex 27 Classic
  • Upper lines: Edelrid 8000U
  • Mid lines: Edelrid 8000U
  • Lower Lines: Liros PPSL/Edelrid 8000U

다운로드

선택 색상

Zone 1
Zone 2
Zone 3
Zone 4

OZONE COLOUR REFERENCE (///)

ABOUT CUSTOM COLOURS

Ozone encourages you to customize your own personal colour combination for your wing. Customization generally incurs a fee. Once you’ve decided you can share your design with your friends, or if you are ready to order, send it to your local Ozone dealer to verify the charge and place the final order.

Please note that because the glider will be built specifically for you in the Ozone factory, payment must be received before production can begin.

FABRIC COLOURS AND UV RESISTANCE

Please be aware that the colour you see on your screen may not accurately represent the actual fabric colour. Secondly, different cloths specifications with the same color name may vary slightly, please see here for an example. Given the wide varience in monitor calibration and the fabric appearance in different light and colour combinations, it is impossible to perfectly represent fabric colour on screen. If you have any doubts about the colours, look at photos of various wings on our website to see them in different light and colour combinations or contact your local dealer to see the fabric in person.

All of the fabric that we use undergoes extensive testing in prototype colour phase to ensure colourfastness, mechanical stability, porosity, and general longevity before we put it into production. Once our fabric is in production, every meter of it is rigorously inspected upon arrival in our factory, and fabric which does not pass our stringent quality control standards is returned to the manufacturer. We are frequently asked, "Which colours last the longest, or have the best UV resistance?" All of the colours that we stock score between 4 and 5 on a scale of 1-5, with 5 being the highest possible rating for longevity.
