- All new Trike-specific design
- Effortless & progressive launch
- Fast & efficient cruise speed, with extended trim range
- Load tested to 625 kg @5.25G, and 410 kg @8G
- Winglets & reflex profile provide incredible stability
- Double tip steering for excellent handling
製品情報
MAKES TRIKE FLYING EASY!
The Triox is the Ozone most purpose-built trike wing. It makes trike flying as easy as possible while delivering fast cruise speeds, high fuel-efficiency, and an effortless launch.
THE LAUNCH
The Triox inflates easily without overshooting, in all conditions. It is roll-stable and very easy to ground-handle. The Trike Launch Assist System means the inflation process is simple and effortless, leaving your hands free to control brakes and throttle.
IN FLIGHT
In the air, the Triox’s handling is progressive and direct. Turns are smooth and coordinated with no dive tendency. Winglets make it highly stable in the air even during a high-powered climb or hands-off cross country flights, leaving the pilot and passenger to sit back and enjoy the ride.
THE TECH
The high performance Shark Nose OZONE Reflex Profile (OZRP) is tuned specifically for powered flight, providing consistent lift and internal pressure through a wide range of angles of attack. The Triox is more stable in accelerated flight, and more stall & spin resistant at low speeds. The aspect ratio and low-drag line plan combined with the OZRP profile make this the most efficient trike wing available.
SPECIAL FEATURES
The TRIOX double tip steering system provides pilots with two options: A 2D system, for agility and precision, and the TST mini-toggles for high speed control. The location low on the risers make these controls easily accessible even with high hang points.
The A-Assist attach points, custom trike brake handles, and TST all feature strong magnetic retainers. Trimmer adjustments are easy thanks to the Triox’s high quality roller buckle.
WINGLETS
Winglets provide significantly greater roll stability and improve spiral behaviour. Glider characteristics are often at odds and we are forced to make compromises in order to reach the best outcomes, but the use of winglets avoids compromise and provides the “best of both worlds” – they increase roll stability without negative outcomes. Regardless of trike type, geometry, thrust, or power, the Triox remains roll-stable!
VERSATILITY
Certified DGAC and load tested to 410 kgs @8G (EN standard) and 625kg @5.25G (DGAC standard), the Triox is available in three sizes, accommodating a wide range of power units and wing loadings. It is suitable for both solo and tandem trike flying, and thanks to the easy launch and flight characteristics is acceptable for a wide range of pilots from recreational to pro. This intuitive and dependable trike wing will last you for many seasons, and we’re excited to hear what you think!
オプションカラー
オーダー情報
The current production time is approximately 107 days from order to shipping (updated daily). Contact your dealer to place your order.
同梱品
オゾンのグライダーには次のアクセサリーが同梱されています：:
You may choose to add something to your order, such as: Easy Bag (stuff bag), Saucisse Bag (video) (concertina packing bag), Glider Backpack, or OZONE Clothing and Accessories.
写真
仕様
| サイズ | 35 | 38 | 41 |
|---|---|---|---|
| セル数 | 48 | 48 | 48 |
| 投影面積 | 30.2 | 32.8 | 35.3 |
| 展開面積 | 34.9 | 38 | 40.9 |
| 投影スパン | 10.54 | 10.98 | 11.4 |
| 展開スパン | 13.37 | 13.93 | 14.5 |
| 投影アスペクト | 3.7 | 3.7 | 3.7 |
| 展開アスペクト | 5.1 | 5.1 | 5.1 |
| ルートコード | 3.37 | 3.51 | 3.7 |
| 機体重量 | 8.3 | 8.49 | 9.22 |
| PPG Weight Range (kg) | 130-350 | 150-380 | 170-410 |
| Load test at 8G | 410 | 410 | 410 |
| Load test at 5.25G (kg) | 625 | 625 | 625 |
| *DGAC Approved | DGAC | DGAC | DGAC |
素材
- Top Surface Cloth: Dominico 30D
- Bottom Surface Cloth: Porcher 9018 E65
- Rib cloth: Porcher 9017 E29 (hard)
- Upper lines: Edelrid 8000U serie
- Mid lines: Edelrid 8000U serie
- Lower Lines: Edelrid 8000U serie
ダウンロード
カスタムカラー
OZONE COLOUR REFERENCE (///)
SHARE YOUR DESIGN
ABOUT CUSTOM COLOURS
Ozone encourages you to customize your own personal colour combination for your wing. Customization generally incurs a fee. Once you’ve decided you can share your design with your friends, or if you are ready to order, send it to your local Ozone dealer to verify the charge and place the final order.
Please note that because the glider will be built specifically for you in the Ozone factory, payment must be received before production can begin.
FABRIC COLOURS AND UV RESISTANCE
Please be aware that the colour you see on your screen may not accurately represent the actual fabric colour. Secondly, different cloths specifications with the same color name may vary slightly, please see here for an example. Given the wide varience in monitor calibration and the fabric appearance in different light and colour combinations, it is impossible to perfectly represent fabric colour on screen. If you have any doubts about the colours, look at photos of various wings on our website to see them in different light and colour combinations or contact your local dealer to see the fabric in person.
All of the fabric that we use undergoes extensive testing in prototype colour phase to ensure colourfastness, mechanical stability, porosity, and general longevity before we put it into production. Once our fabric is in production, every meter of it is rigorously inspected upon arrival in our factory, and fabric which does not pass our stringent quality control standards is returned to the manufacturer. We are frequently asked, "Which colours last the longest, or have the best UV resistance?" All of the colours that we stock score between 4 and 5 on a scale of 1-5, with 5 being the highest possible rating for longevity.
